Toro 51480A - Edging; Maintenance; Replacing the Spool

Edging
Toconvertthetrimmertoanedger,presstherotatorbuttonand
rotatetheheadasshowninFigure9.
g015660
Figure9
1.Rotatorbutton2.Edgerguide
OperatingTips
•Keepthetrimmertiltedtowardtheareabeingcut;thisisthe
bestcuttingarea.
•Thestringtrimmercutswhenpassingtheunitfromleftto
right.Thisavoidsthrowingdebrisatyou.
•Usethetipofthestringtodothecutting;donotforcethe
stringheadintouncutgrass.
•Usingthetrimmeralongwireandpicketfences,stoneand
brickwalls,curbs,andwoodcancausethelinetorapidly
wearandevenbreak.
•Avoidtreesandshrubs.Treebark,woodmoldings,siding,
andfencepostscaneasilybedamagedbythestrings.
g023661
Figure10
1.Directionofrotation3.Stringpath
2.Idealcuttingrange
Maintenance
Aftereachuseofthetrimmer,completethefollowing:
1.Wipethetrimmercleanwithadampcloth.Donothosethe
trimmerdownorsubmergeitinwater.
2.Wipeorscrapecleananydebrisfromthecutting-headarea.
3.Checkandtightenallfasteners.Ifanypartisdamagedor
lost,repairorreplaceit.
4.Brushdebrisawayfromtheairintakeventsonthemotor
housingtopreventthemotorfromoverheating.
ReplacingtheSpool
Note:Useonly1.65mm(0.065in)diametermonolament
string.Forbestperformance,useonlyT ororeplacementstring
(PartNo.88512).
Important:Usingalargerdiameterstringmaycausethe
motortooverheatandfail.
1.Pushinthetabsonthesideofthespoolretainer(Figure11).
g023662
Figure11
1.Spoolretainer3.Slots
2.Spool
4.Tabs
2.Pullthespoolretaineruptoremoveit.
3.Removethespool.
4.Installthenewspool,makingsurethatthestringsare
capturedintheretainingslotsonthenewspool.
Note:Makesurethattheendsofthestringsextend
approximately152mm(6inches).
5.Installthenewspoolsothatthestringendsalignwith
theeyeletsinthestringhead,andthreadthestringends
throughtheeyelets.
8
