Toro 51480A - Adjusting the Trimmer Height and Base Position; Operation; Connecting to a Power Source

4
AdjustingtheTrimmer
HeightandBasePosition
NoPartsRequired
Procedure
•T oadjusttheauxiliaryhandleheight,releasetheauxiliary
handlelatch,slidetheauxiliaryhandleupordowntothe
desiredheight,thensecuretheauxiliaryhandleinplaceby
closingtheauxiliarylatch(Figure4).
g015655
Figure4
1.Auxiliaryhandle3.Height-adjustmentlatch
2.Auxiliary-handlelatch
•T oadjustthetrimmerheight,opentheheightadjustment
latch,thenslidetheshaftupordowntodesiredheight,
securingitinplacewiththelatch(Figure4).
•T oadjustthepositionofthebase,pressdownontherotator
buttonlocatedatthebaseoftheshaft,thenmovethebase
tofacethedesireddirection(Figure5).
g015683
Figure5
1.Rotatorbutton
Operation
ConnectingtoaPower
Source
WARNING
Ifyoudonotfullyseattheextensioncordontheinlet
plug,thelooseplugcouldleadtooverheatingand
causeare,possiblyburningyouorothers.
Ensurethatyoufullyseatthecordonthepluganduse
thecordlockfeaturetosecurethecord.
NOTICE!Donotuseadamagedcord.
g015693
Figure6
1.Inletplug
3.Cordlock
2.Extensioncord
