Note:Donotmixfuelandoilinthefueltank.Oilat
roomtemperaturemixeseasierandmorethoroughly
thancoldoil.Oilbelow0°C(32°F)requiresadditional
mixing.
UsingStabilizer/Conditioner
Usefuelstabilizer/conditionerinthemachinetokeep
thefuelfreshlongerwhenusedasdirectedbythe
fuel-stabilizermanufacturer.
Important:Donotusefueladditivescontaining
methanolorethanol.
Addtheamountoffuelstabilizer/conditionertofresh
fuelasdirectedbythefuel-stabilizermanufacturer.
FillingtheFuelTank
Fuel-tankcapacity:1.1L(36oz)
Refertoyourengineowner’smanualforadditional
information.
FillthefueltankasshowninFigure8.
g230458
Figure8
PerformingDaily
Maintenance
Beforestartingthemachineeachday,performthe
EachUse/DailyprocedureslistedinMaintenance
(page15).
RemovingandInstalling
theTines
1.Parkthemachineonalevelsurface,shutoffthe
engine,andallowtheenginetocool.
2.Removethehairpincotterfromeachendofthe
tineshaft.
g334235
Figure9
1.Hairpincotter
3.Slidethetinesofftheshaft.
4.Slidetheinnertines(“B”and“C”)ontheshaft.
Note:Thelettersarestampedonthetines.
Slidetine“B”ontheleftsideoftheshaft,and
slidetine“C”totherightsideoftheshaft.
g334237
Figure10
5.Slidetheoutertines(“A”and“D”)ontheshaft,
sothattheorderofthetinesis“A”,“B”,“C”,“D”,
whenviewedfromtheoperatingposition.
Note:Ensurethatthehubcollarsonboththe
leftandrightpairsoftinesfaceeachotherto
ensureadequatespacingbetweenthetine
blades.
