Toro 600 - Setup; Installing the Caster Wheels

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
1
Nopartsrequired
–
Installthecasterwheels.
2
Nopartsrequired
–
Connectthelowerlinkarms.
3
Nopartsrequired
–
Connecttheupperlink.
4
Nopartsrequired
–
AdjustthePTOshaftlength.
5
Nopartsrequired
–
ConnectthePTOshaft.
6
Nopartsrequired
–
Adjusttheswaylinks.
7
Nopartsrequired
–
Adjustthe3-point-liftstop.
8
Nopartsrequired
–
Removetheblowerfromthetractor.
9
Nopartsrequired
–
Greasetheblower.
MediaandAdditionalParts
Description
Qty.
Use
Operator'sManual
1
Reviewthemanualbeforeoperatingthemachine.
DeclarationofConformity
1
ForCEcompliance.
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
1
InstallingtheCasterWheels
NoPartsRequired
Procedure
Installacasterwheelassemblybetweeneachcaster
forkwith4washers,anaxle,and2cotterpins(Figure
2).
g011990
Figure2
1.Wheelassembly3.Axle
2.Casterfork
