Shut off engine and remove wire from spark
plug. Remove ignition key.
Shift transaxle into 1st gear and engage parking
brake.
Remove cutting unit: refer to Removing/Installing
Cutting Unit, page 22.
Grasp end of blade using a rag or thickly
padded glove; then remove blade bolt, curved washĆ
er, blade stiffener and blade (Fig. 19).
26) Since blade bolt is tightened to 45Ć60 ftĆlb
(61Ć81 Nm) at the factory, it may be difficult to reĆ
move. If the bolt cannot be removed, contact an AuĆ
thorized TORO Service Dealer or a service station"
for assistance.
394
1
2
-+74)
3
Using a file, sharpen cutting edge at both ends
of the blade (Fig. 20).
$
,)'. '766)4 &/%() )8)4: 6-0) '766-1+ 71-6 -5
4)028)( * &/%() &2/6 ,2/(-1+ &/%() -5 /225)
6-+,6)1 -6 62 ; *6;/& ; ·0 * &/%() 24
5%-/ -+ %6 )1( 2* &/%() -5 9241 )42()(
24 '4%'.)( 4)3/%') 6,) &/%() )3/%') 6,)
&/%() -* -6 -5 &)16 24 276;2*;&%/%1') /9%:5
75) % +)17-1) ! 4)3/%')0)16 &/%() 62
)1574) 5%*)6: %1( &)56 3)4*240%1') #
" $;! !
-+74)
!
#$
!
!
!! ,%43)1 623 5-() 2* 6,) &/%() %1(
0%-16%-1 24-+-1%/ '766-1+ %1+/) 62 )1574) % 5,%43
'766-1+ )(+) !,) &/%() 9-// 4)0%-1 &%/%1')( -*
5%0) %02716 2* 0%6)4-%/ -5 4)028)( *420 &26,
'766-1+ )(+)5
Check balance of blade by putting it on a blade
balancer. (An inexpensive balancer can be purĆ
chased at a hardware store.) A balanced blade will
stay in a horizontal position on the balancer. By conĆ
trast, a blade that is not balanced will settle to the
heavy side. If blade is not balanced, file more materiĆ
al off cutting edge of the blade. Continue to file and
check the blade until it is balanced.
In sequence, install blade, blade stiffener, curved
washer and blade bolt (Fig. 19). The concave side of
the curved washer must point toward the blade.
Tighten blade bolt to 45Ć60 ftĆlb (61Ć81 Nm).
!! %.) 574) '766-1+ )(+) 2* &/%() -5
%9%: *420 029)4 ,275-1+
Reinstall cutting unit: refer to Removing/Installing
Cutting Unit, page 22.
