g001059

Figure2

DieselMachineShown

2.Raisetherearofthemachineandsupportit

withjackstands.

g010180

Figure3

GasolineMachineShown

g001089

Figure4

DieselMachineShown

3.Removethewheelnutsfrombothsidesofthe

machineandremovetherightangleretaining

plate.Discardthescrewsandretainingplate.

g001088

Figure5

DieselMachineShown

4.Mountthewheelswiththevalvestemtothe

outsideandsecurethemwiththewheelnuts

previouslyremoved.

5.Torquethewheelnutsto128N∙m(95ft-lb).

6.Removethejackstands.

g010181

Figure6

GasolineMachineShown

g001071

Figure7

DieselMachineShown
