2
AddingFueltotheMachine
NoPartsRequired
Procedure
Addfueltothemachinebeforestartingit.Refer
toyourOperator’sManualforthecorrectfueland
procedure.
3
CheckingtheEngine-Oil
Level
NoPartsRequired
Procedure
Beforeyoustarttheengineandusethemachine,
checktheoillevelintheenginecrankcase;referto
theOperator'sManual.
4
CheckingtheTirePressure
NoPartsRequired
Procedure
Airpressurespecication:90kPa(13psi)
Note:Checkthetirepressurebeforestartingthe
machine.RefertoyourOperator’sManualforthe
correcttiretype,correctairpressureneeded,and
procedure.
5
CheckingtheWheelLug
NutTorque
NoPartsRequired
Procedure
Beforeyoustarttheengineandusethemachine,
checkthewheellugnuttorque;refertoCheckingthe
WheelLugNutsintheOperator'sManual
6
CheckingtheGrass
Deector
NoPartsRequired
Procedure
Ifthereareplastictiesholdingthegrassdeectorup,
removethemandlowerthedeectorintoplace.
WARNING
Anuncovereddischargeopeningcouldallow
themachinetothrowobjectsintheoperator's
orbystander'sdirectionandresultinserious
injuryordeath.Also,contactwiththeblade
couldoccur.
Neveroperatethelawnmowerunlessyou
installacoverplate,amulchplate,grass
deectororbagger.
1.Ensurethat1endofthespringisinstalled
behindthedeckedgebeforeinstallingthebolt
asshowninFigure8.
2.Placetheotherendofthespringaroundthe
grassdeector(Figure8).
Important:Thegrassdeectormustbefree
torotatewithdownwardtension.Liftthe
deectoruptothefullyopenpositionand
ensurethatitrotatesfreely,withoutbinding
intothefullydownposition.
