Toro 74024 Setup Instructions

g021181
Figure8
1.Grassdeector3.Endofthespring
2.Spring
4.Deckedge
7
InstallingaBattery
DieselMachinesOnly
Partsneededforthisprocedure:
2J-bolt
2Wingnut
1Hold-downclamp
Procedure
Important:Thisprocedureonlyappliesto
machinesthatdonotcomewithabattery
installed.
Purchasea12Vbatteryandinstallitintothemachine.
Theenginerequiresaminimumof540CCA.
Usethehardwareincludedtoinstallthenewbattery.
RefertoInstallingtheBatteryintheOperator's
Manual.
8
InstallingaBattery
GasolineMachinesOnly
Partsneededforthisprocedure:
1
Clamp
2
Wingnut(1/4inch)
2Batteryhold-down
Procedure
Important:Thisprocedureappliesonlyto
machinesthatdonotcomewithabattery
installed.
1.Purchasea12Vbattery.
Modelswitha29hpengineandbelowrequirea
batterywithaminimumof260CCA.
Modelswitha30hpengineandhigherrequirea
batterywithaminimumof340CCA.
2.Locatethebattery-mountinghardwareand
installitintothemachine.RefertoInstallingthe
BatteryintheOperator'sManual.
9
ChargingtheBattery
NoPartsRequired
Procedure
WARNING
Chargingthebatteryproducesgassesthat
canexplodeandcauseseriousinjury.
•Keepcigarettes,sparksandamesaway
fromthebattery.
•Makesuretheignitionswitchisoff.
•Ventilatewhenchargingorusingthe
batteryinanenclosedspace.
Important:Donotrunthemachinewiththe
batterydisconnected;electricaldamagemay
occurtotheengine.
