Toro 74024 Setup Instructions

Chargethebattery;refertotheOperator'sManual
forinstructions.
g001084
Figure9
10
InstallingtheSeat
InternationalMachinesUsing
GasolineOnly
Partsneededforthisprocedure:
1
Seat
1
Seatplate(xedseatsonly)
8
Flangenuts(3/8inch)—xedseatsonly
4
Spacers(3/8inch)—xedseatsonly
4
Flangenuts(3/8inch)—tiltingseatsonly
2
Longspacers(tilting,deluxeseatsonly)
4
Shortspacers(tilting,deluxeseatsonly)
InstallingtheSeatonModelswith
aFixedSeat
1.Removethehydraulic-unitshroudfromthe
machine.
g010175
Figure10
1.Hydraulic-unitshroud2.Bolts
2.Removethe4nutsholdingtheseatplatetothe
machine.Discardthesenuts,theyareusedfor
shippingonly.
g010182
Figure11
3.Securetheseatplatetotheseatwith4spacers
and4angenuts(3/8inch).
6
