Toro 74310 Setup Instructions

g026151
Figure8
1.Frontcaster3.Plywoodbetweenthe
drivewheels
2.Rear-deckrollers
4.Woodrampforthefront
casters
Note:Ensurethatthedischargetubedoesnot
catchonthecratewhendrivingthemachineoff
thecrate(Figure4).
WARNING
Operatingthemowerwithoutthelocking
pinssecurelylatchedcanresultinthe
mowerdeckfoldingupunexpectedly.
Themowerdeckfoldingupunexpectedly
cancauseseriousinjury.
Alwaysoperatethemowerwiththe
lockingpinssecurelylatched.
19.Drivethemachineoffthecrate.
RemovingtheMachinefromthe
CrateUsingaHoist
CAUTION
ThemowerdeckisshippedintheUp
position,butnotlatched.Removingshipping
reinforcementswithoutsupportingthefront
ofthedeckcausesthedecktodrop,which
mayresultininjuryorpropertydamage.
Alwayssecurelysupportthefrontofthedeck
whilesettingupthemachine.
1.Removetherearcaster-wheelassemblyfrom
insidethehopper.
2.Removetheboltholdingtherearframetothe
crate(Figure11).
3.Liftthefrontofthehopperup.
Note:Usecarewhenhoistingthemachineto
preventdamagingthehopper.
4.Usingthehoist,liftthemachineatthelocation
showninFigure9.
g026283
Figure9
1.Withthehopperup,liftthemachineoneachsidehere
CAUTION
Raisingthemowerdeckforservice
ormaintenancerelyingsolelyon
mechanicalorhydraulicjackscouldbe
dangerous.Themechanicalorhydraulic
jacksmaynotbeenoughsupportormay
malfunctionallowingthemachinetofall,
whichcouldcauseinjury.
Donotrelysolelyonmechanical
orhydraulicjacksforsupport.Use
adequatejackstandsorequivalent
support.
5.Raisetherearofthemachineapproximately
25.4to30.5cm(10to12inches)andsupportit
withjackstandsorequivalentsupport(Figure
10).
5
