Toro 74310 Setup Instructions

g025171
Figure13
1.Deck-supportpin
3.Side-struthardware
2.Strutbetweenthe
deck-supportpins
21.Withthedeck-lockingpinspulledoutinthe
unlockposition,carefullylowerthedeck(Figure
14).
g006790
Figure14
1.Deck-lifthandle
3.Pushthedeck-lockingpin
inandrotatetowardthe
fronttolock.
2.Rotatethedeck-locking
pintowardtherearand
pulloutwardtounlock.
22.Pushthedeck-lockingpinsinwardandrotate
themforwardtosecurelylockthedeckinthe
loweredposition.
3
InstallingtheROPS
InternationalMachinesOnly
Partsneededforthisprocedure:
1
ROPSKit(soldseparately)
Procedure
InstalltheROPSKitasdescribedintheInstallation
Instructionsforthekit.
4
InstallingthePTO-Shaft
Guards
InternationalMachinesOnly
Partsneededforthisprocedure:
1Longguard
1
Guard
4
Bolt(1/4x1inch)
4
Flatwasher(1/4inch)
4
Retainernut(1/4inch)
Procedure
Note:Thisprocedureisonlyforinternational
machines.
Note:Theguardsarelocatedinthehopperofthe
machine.
Note:Theguardsareshippedassembledtogether
withthepartslistedabove.Ensuretheguardsare
installedafterloweringthemowerdeck.
1.Shutofftheengine,waitforallmovingparts
tostop,andremovekey.Engagetheparking
brake.
2.Lowerthemowerdeck.
3.Loosentheboltsattachedtotherubberguard
(Figure15).
7
