Toro 74395 - Grass Deflector; Converting to Side Discharge Mode

GrassDeector
Themowerhasahingedgrassdeectorthatdisperses
clippingstothesideanddowntowardtheturf.
DANGER
Withoutthegrassdeector,dischargecover,or
completegrasscatcherassemblymountedin
place,youandothersareexposedtobladecontact
andthrowndebris.Contactwithrotatingmower
blade(s)andthrowndebriswillcauseinjuryor
death.
•Neverremovethegrassdeectorfromthemower
becausethegrassdeectorroutesmaterialdown
towardtheturf.Ifthegrassdeectorisever
damaged,replaceitimmediately.
•Neverputyourhandsorfeetunderthemower.
•Nevertrytocleardischargeareaormower
bladesunlessyoumovethebladecontrolswitch
toOffandrotatetheignitionkeytoOff.Also
removethekeyandpullthewireoffthespark
plug(s).
ConvertingtoSideDischarge
Mode
WARNING
Openholesinthemowerdeckexposeyouand
otherstothrowndebris.Debristhrownoutofthe
holesinthemowerdeckcancauseinjury.
•Neveroperatethemowerdeckwithouthardware
mountedinallholesinthemowerdeck.
•Installhardwareinthemountingholeswhen
youremoveabafe.
1.Stoptheengineandremovetheignitionkey.
2.RemovethemowerdeckasdescribedinRemovingthe
Mower(page42).
3.Turnthemowerdeckupsidedown.
4.Removetheexistingmowerbladesinstalledonyour
mowerdeck.RefertoRemovingtheBlades(page40).
5.Removeanydebrisandgrassclippingsfromthe
undersideofthemowerdeck.
6.Removethelefthandbafefromthemowerdeck
shownin
Figure26.Plugtheopenholeswithnutsand
bolts.
G018654
1
2
3
1
4
Figure26
1.Locknut
3.Leftbafe
2.Weldedposts4.Plugtheholeswithnuts
andboltshere.
7.Removetherighthandbafefromthemowerdeck
showninFigure27.Plugtheopenholeswithnutsand
bolts.
G021583
1
2
3
4
1
5
5
Figure27
Thedeectorhasbeenremovedforthepurposeofclarity.
1.Flangenut4.Weldedposts
2.Carriagebolt
5.Plugtheholeswithnuts
andboltshere.
3.Righthandbafe
8.RemovetheRecycler
®
bracketfromthemowerdeck
showninFigure28.
23
