Toro 74395 - Leveling the Mower Deck

LevelingtheMowerDeck
Checktoensurethemowerdeckislevelanytimeyouinstall
themowerorwhenyouseeanunevencutonyourlawn.
Themowerdeckmustbecheckedforbentbladespriorto
leveling;anybentbladesmustberemovedandreplaced.Refer
totheCheckingforBentBladesprocedurebeforecontinuing.
Themowerdeckmustbeleveledside-to-siderstthenthe
fronttorearslopecanbeadjusted.
Requirements:
•Themachinemustbeonalevelsurface.
•Allfourtiremustbeproperlyinated.RefertoChecking
theTirePressureintheDriveSystemMaintenance
section.
LevelingtheMowerfromSide-to-Side
Themowerbladesmustbelevelfromsidetoside.Checkthe
side-to-sidelevelanytimeyouinstallthemowerorwhenyou
seeanunevencutonyourlawn.
1.Parkthemachineonalevelsurfaceanddisengagethe
bladecontrolswitch.
2.Movethemotioncontrolleversoutwardtothepark
position,stoptheengine,removethekey,andwaitfor
allmovingpartstostopbeforeleavingtheoperating
position.
3.Checktheairpressureofallfourtires.Ifneeded,adjust
totherecommendedination;refertoCheckingthe
TirePressureintheDriveSystemMaintenancesection.
4.Settheheight-of-cutlevertothe76mm(3inch)
position.
5.Carefullyrotatetheblade(s)sidetoside(Figure60).
Measurebetweentheoutsidecuttingedgesandthe
atsurface(
Figure60).Ifbothmeasurementsarenot
within5mm(3/16inch),anadjustmentisrequired;
continuewiththisprocedure.
G005278
1
2
2
3
3
4
4
Figure60
1.Bladessidetoside
3.Outsidecuttingedges
2.Sailareaofblade
4.Measurehere
6.Movetotheleftsideofthemachine.Loosen,butdo
notremove,therearlockingnutonthehangerbracket
(Figure61).
7.Loosenthesidelockingnutonthehangerbracket
justenoughtoallowtheeccentricplatetobeadjusted
(Figure61).Usea3/8inchdriveextensiononasocket
wrenchtomanipulatetheeccentricplate.Usethe
wrenchtorepositiontheheightofthemowerdeckand
adjustitsothatthemeasurementstakeninstep5are
within5mm(3/16inch).
8.Stopthedeckattheadjustedpositionandtightenthe
sidelockingnutonthehangerbrackettoholdthenew
position(Figure61).Tightentherearlockingnuton
thehangerbracket.
9.Continuelevelingthedeckbycheckingthefront-to-rear
bladeslope;refertoAdjustingtheFront-to-RearBlade
Slope.
3
G005074
1
2
3
4
5
6
Figure61
1.Hangerbracket4.Eccentricadjustmentplate
2.Rearlockingnut
5.Socketwrenchhole
3.Sidelockingnut6.Socketwrenchwith3/8
inchextension
AdjustingtheFront-to-RearBlade
Slope
Checkthefront-to-rearbladelevelanytimeyouinstallthe
mower.Ifthefrontofthemowerismorethan7.9mm
(5/16inch)lowerthantherearofthemower,adjusttheblade
levelusingthefollowinginstructions:
1.Parkthemachineonalevelsurfaceanddisengagethe
bladecontrolswitch.
