Toro 74626 - Fuel System Maintenance; Replacing the In-line Fuel Filter

FuelSystem
Maintenance
DANGER
Incertainconditions,gasolineisextremely
ammableandhighlyexplosive.Areorexplosion
fromgasolinecanburnyouandothersandcan
damageproperty.
•Performanyfuelrelatedmaintenancewhenthe
engineiscold.Dothisoutdoorsinanopenarea.
Wipeupanygasolinethatspills.
•Neversmokewhendraininggasoline,andstay
awayfromanopenameorwhereasparkmay
ignitethegasolinefumes.
ServicingtheEmissionsFilter
ServiceInterval:Every100hours/Yearly(whichevercomes
rst)
Model74625only
Note:CARBcompliantmodel74625isequippedwitha
maintenancefreeemissionscanisterandhasanemissions
ltertobeserviced.
Thelterislocatedbehindtheoperatorsseat,nexttothe
engine.Pullthelteroffofthehoseandreplacewithanew
lter.
g020178
1
2
Figure41
1.Emissionslter
2.Emissionscanister
ReplacingtheIn-lineFuel
Filter
ServiceInterval:Every100hours—Replacethein-linefuel
lter
Neverinstalladirtylterifitisremovedfromthefuelline.
1.Parkthemachineonalevelsurfaceanddisengagethe
bladecontrolswitch.
2.Movethemotioncontrolleversoutwardtothepark
position,stoptheengine,removethekey,andwaitfor
allmovingpartstostopbeforeleavingtheoperating
position.
3.Locatethefuellteronthesideoftheengineasshown
in
Figure42.
g017471
1
2
3
4
5
Figure42
1.Fuellinefromtank
4.Fuellinetoengine
2.In-lineFuellter
5.Hoseclamp
3.Flowdirectionarrow
4.Squeezetheendsofthehoseclampstogetherandslide
themawayfromthelter(Figure42).
5.Removethelterfromthefuellines.
6.Installanewlterwiththeowdirectionarrowcoming
fromthefueltankandpointingtotheengine.Move
thehoseclampsclosetothelter(Figure42)tosecure
itinplace.
43
