Toro 74776 - Installing the Mower; Replacing the Grass Deflector

8.Slidethemowerdeckoutfromunderneaththe
machine.
Note:Retainallpartsforfutureinstallation.
InstallingtheMower
1.Parkthemachineonalevelsurfaceanddisengagethe
blade-controlswitch.
2.Movethemotion-controlleversoutwardtothePARK
position,shutofftheengine,removethekey,and
waitforallmovingpartstostopbeforeleavingthe
operatingposition.
3.Slidethemowerunderthemachine.
4.Lowertheheight-of-cutlevertothelowestposition.
5.Lifttherearofthemowerdeckandguidethehanger
bracketsovertherearliftrod(Figure59).
6.Attachthefrontsupportrodtothemowerdeckwith
theclevispinandhairpincotter(Figure58).
7.Installthemowerbeltontotheenginepulley.
ReplacingtheGrassDeector
Inspectthegrassdeectorfordamagebeforeeachuse.
Replaceanydamagedpartsbeforeuse.
1.Disengagethespringfromthenotchinthedeector
bracketandslidetherodoutoftheweldeddeck
brackets,spring,anddischargedeector(Figure60).
g017617
1
3
2
4
5
g017617
Figure60
1.Rod4.Deckbrackets
2.Spring5.Springinstalledoverthe
rod
3.Deector
2.Removethedamagedorworndischargedeector.
3.Positionthenewdischargedeectorwiththebracket
endsbetweentheweldedbracketsonthedeckas
showninFigure61.
4.Installthespringontothestraightendoftherod.
5.Positionthespringontherodasshowninsothe
shorterspringendiscomingfromundertherodbefore
42
