Toro 74830 - Checking the Engine Oil Level; Operating the Parking Brake; Operating the Throttle; Operating the Choke

G010016
G010475
1
2
4
3
Figure10
CheckingtheEngineOilLevel
Beforeyoustarttheengineandusethemachine,check
theoillevelintheenginecrankcase;refertoChecking
theEngineOilLevel.
OperatingtheParkingBrake
Alwayssettheparkingbrakewhenyoustopthe
machineorleaveitunattended.
SettingtheParkingBrake
G010078
1
2
Figure11
ReleasingtheParkingBrake
G010079
1
2
Figure12
OperatingtheThrottle
ThethrottlecontrolcanbemovedbetweenFastand
Slowpositions(Figure13).
Alwaysusethefastpositionwhenturningonthe
mowerdeckwiththebladecontrolswitch(PTO).
G010289
Figure13
OperatingtheChoke
Iftheengineiscold,usethechoketostarttheengine.
Engagethechokebymovingthethrottleleverpastthe
Fastsettinguntilitstops(Figure14).
G010288
Figure14
Movethethrottleleverbacktodisengagethechoke
aftertheenginehasstarted.
17
