The Toro Company – 1997
All Rights Reserved
Printed in USA
i
Figures
637
1. Model and serial number decal
637
1
2
3
(Unit shown on right side)
1. Short spacer
2. Long spacer
3. Pushnut
m-3277
1
4
5
2
3
Models 38409 & 38414
1. Chute ring
2. Discharge chute
3. Chute handle
4. Carriage bolt
5. Lock nut
1
2
3
