CouplerFittingNo.95-0985[Qty.2],and
HydraulicFittingNo.340-77[Qty.2])tothe
reversetractionpressuretestport(Figure32)
andthereversefour-wheeldrivepressureport
(
Figure33).
Figure32
1.Reversetractionpressuretestport
Figure33
1.Reversefour-wheeldrivepressuretestport
JackingPoints
Therearejackingpointslocatedatthefrontandrear
ofthemachine.
•Ontheframeattheinsideofeachfrontdrivetire
•Atthecenteroftherearaxle
TieDowns
Therearetiedownslocatedatthefront,rearandsides
ofthemachine.
•Oneachsideoftheframebythesidecuttingunit
liftarms
•Frontcenteroftheoperator'splatform
•Therearbumper
OperatingCharacteristics
Practicedrivingthemachinebecauseithasahydrostatic
transmissionanditscharacteristicsaredifferentthan
manyturfmaintenancemachines.Somepointsto
considerwhenoperatingthetractionunit,cutting
unit,orotherimplementsarethetransmission,engine
speed,loadonthecuttingbladesorotherimplement
components,andtheimportanceofthebrakes.
Tomaintainenoughpowerforthetractionunitand
implementwhileoperating,regulatethetractionpedal
tokeeptheenginespeedhighandsomewhatconstant.
Agoodruletofollowistodecreasethegroundspeed
astheloadontheimplementincreases,andincreasethe
groundspeedastheloaddecreases.
Therefore,allowthetractionpedaltomovebackward
astheenginespeeddecreases,anddepressthepedal
slowlyasthespeedincreases.Bycomparison,when
drivingfromoneworkareatoanother,withnoload
andcuttingunitraised,havethethrottleintheFast
positionanddepressthetractionpedalslowlybutfully
toattainmaximumgroundspeed.
Thebrakescanbeusedtoassistinturningthemachine.
However,usethemcarefully,especiallyonsoftor
wetgrassbecausetheturfmaybetornaccidentally.
Anotherbenetofthebrakesistomaintaintraction.
Forexample,insomeslopeconditions,theuphillwheel
slipsandlosestraction.Ifthissituationoccurs,depress
theuphillturnpedalgraduallyandintermittentlyuntil
theuphillwheelstopsslipping,thus,increasingtraction
onthedownhillwheel.
Useextracarewhenoperatingthemachineonslopes.
Makesurethattheseatlatchisproperlysecuredandthe
seatbeltisbuckled.Driveslowlyandavoidsharpturns
onslopestopreventrollovers.Forsteeringcontrol,the
cuttingunitmustbeloweredwhengoingdownhill.
WARNING
Thiscuttingunitisdesignedtodriveobjectsinto
thegroundwheretheyloseenergyquicklyingrass
areas.However,carelessoperation,combinedwith
terrainangle,ricochets,orimproperlypositioned
safetyguardcanleadtothrownobjectinjuries.
•Whenapersonorpetappearssuddenlyinor
nearthemowingarea,
stop mo wing .
•Donotresumemowinguntiltheareaiscleared.
30

Toro Groundsmaster 4110-D Specifications

General

Fuel Type	Diesel
Number of Blades	5
Transmission	Hydrostatic
Deck Lift	Hydraulic
Turning Radius	18 inches
