Toro MX 5000 User Manual

ProductOverview
g028411
Figure4
1.Footrest
8.Gas-tankcap
2.Deector9.SmartSpeed™lever
3.Height-of-cutlever
10.Reardrivewheel
4.Motion-controllever11.Mowerdeck
5.Controlpanel
12.Anti-scalproller
6.Operatorseat
13.Frontcasterwheel
7.Engine
Controls
Becomefamiliarwithallthecontrolsbeforeyoustart
theengineandoperatethemachine.
ControlPanel
g032603
Figure5
1.Throttlecontrol
3.Blade-controlswitch
(powertakeoff)
2.Chokecontrol
4.Keyswitch
KeySwitch
Thekeyswitch,usedtostartandshutofftheengine,
has3positions:OFF,RUN,andSTART.Referto
StartingtheEngine(page21).
ThrottleControl
Thethrottlecontrolstheenginespeed,andithasa
continuous-variablesettingfromtheSLOWtoFAST
position(Figure5).
ChokeControl
Usethechokecontroltostartacoldengine.
Blade-ControlSwitch(Power
Takeoff)
Theblade-controlswitch,representedbya
power-takeoff(PTO)symbol,engagesand
disengagespowertothemowerblades(Figure5).
Motion-ControlLevers
Usethemotion-controlleverstodrivethemachine
forward,reverse,andturneitherdirection(Figure4).
13
