1
InstallingtheUpperHandle
Partsneededforthisprocedure:
4Handlebolts
4
Curvedwashers
4Locknuts
Procedure
Note:Donotremovetherubberbandonthecablesuntil
youhaveinstalledtheupperhandle.
1.Liftandrotatetheupperhandleandpositionitover
thelowerhandle(Figure4).
Important:Routethecablesattachedtothe
QuickStickinsidetheupperhandlelegsand
ensurethatthecablesandthewireforthe
headlightarenotpinchedbetweenthehandle
sections.
Figure4
1.Cables
2.Securetheupperhandlewith4handlebolts,4curved
washers,and4locknutsfromtheloosepartsbag
(
Figure5).
Figure5
2
InstallingtheWheelClutch
CableEnds
NoPartsRequired
Procedure
1.Unwrapthecableendsfromthelowerhandle
(Figure6).
Figure6
2.Routeeithertheleftorrightcableendoverthelower
handleandinsertthecableendintotheholeinthe
correspondingwheelclutchlever(Figure7).
8

Toro power max 928 Specifications

General

Engine Type	4-Cycle OHV
Engine Displacement	252cc
Start Type	Electric Start
Clearing Width	28 in
Intake Height	21 in
Stages	2
Auger Material	Steel
