Toro Recycler 20332C - Recycling the Clippings; Bag-on-Demand Lever Operation; Installing the Grass Bag; Grass Bag Installation

Figure14
1.Notches
3.Grassbagpin(2)
2.Reardeector
2.Installthegrassbag,ensuringthatthepinsonthe
bagrestinthenotchesonthehandle(Figure14).
3.Lowerthereardeector.
RemovingtheGrassBag
Toremovethebag,reversethestepsabove.
OperatingtheBag-on-DemandLever
Thebag-on-demandfeatureallowsyoutoeithercollect
orrecyclegrassandleafclippingswhilethegrassbag
isattachedtothemower.
•Forbaggingthegrassandleafclippings,pressthe
buttononthebag-on-demandleverandmovethe
leverforwarduntilthebuttonontheleverpopsup
(Figure15)
Figure15
1.Bag-on-demandlever(inbaggingposition)
•Forrecyclingthegrassandleafclippings,pressthe
buttonontheleverandmovetheleverrearward
untilthebuttonontheleverpopsup.
Important:Forproperoperation,remove
anygrassclippingsanddebrisfromthe
bag-on-demanddoorandthesurrounding
opening(Figure16)beforeyoumovethe
bag-on-demandleverfromonepositionto
another.
WARNING
Thebladeissharp;contactingthebladecan
resultinseriouspersonalinjury.Also,anopen
reardischargeareacouldallowsmallstones
andothersimilardebristobethrowninthe
operator'sorbystander'sdirectionandresultin
seriouspersonalinjuryordeathtotheoperator
orbystanders.
Stoptheengineandwaitforallmovingpartsto
stopbeforecleaningthebag-on-demanddoor
andthesurroundingopening.
