Toro Recycler 20332C - Side-discharging the Clippings; Installing the Side Discharge Chute; Removing the Side Discharge Chute

Figure16
1.Cleanhere
Side-dischargingtheClippings
Usethesidedischargeforcuttingverytallgrass.
Ifthegrassbagisonthemowerandthebag-on-demand
leverisinthebaggingposition,movethelever
totherecyclingposition(refertoOperatingthe
Bag-on-DemandLever).
WARNING
Thebladeissharp;contactingthebladecanresult
inseriouspersonalinjury.
Stoptheengineandwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
InstallingtheSideDischargeChute
Liftupthesidedeectorandinstallthesidedischarge
chute(Figure17).
Figure17
RemovingtheSideDischargeChute
Toremovethesidedischargechute,liftuptheside
deector,removethesidedischargechute,andlower
thesidedischargedeector.
11
