InstallingtheGrassBag
1.Raiseandholdupthereardeector(Figure14).
Figure14
1.Notches
3.Grassbagpin(2)
2.Reardeector
2.Installthegrassbag,ensuringthatthepinsonthe
bagrestinthenotchesonthehandle(
Figure14).
3.Lowerthereardeector.
RemovingtheGrassBag
Toremovethebag,reversethestepsabove.
OperatingtheBag-on-DemandLever
Thebag-on-demandfeatureallowsyoutoeithercollect
orrecyclegrassandleafclippingswhilethegrassbag
isattachedtothemower.
•Forbaggingthegrassandleafclippings,pressthe
buttononthebag-on-demandleverandmovethe
leverforwarduntilthebuttonontheleverpopsup
(
Figure15).
Figure15
1.Bag-on-demandlever(inbaggingposition)
•Forrecyclingthegrassandleafclippings,pressthe
buttonontheleverandmovetheleverrearward
untilthebuttonontheleverpopsup.
Important:Forproperoperation,removeanygrass
clippingsanddebrisfromthebag-on-demanddoor
andthesurroundingopening(
Figure16)beforeyou
movethebag-on-demandleverfromoneposition
toanother.
WARNING
Thebladeissharp;contactingthebladecanresult
inseriouspersonalinjury.Also,anopenrear
dischargeareacouldallowsmallstonesandother
similardebristobethrownintheoperator’sor
bystander’sdirectionandresultinseriouspersonal
injuryordeathtotheoperatororbystanders.
Stoptheengineandwaitforallmovingpartsto
stopbeforecleaningthebag-on-demanddoorand
thesurroundingopening.
