Figure25
1.Fuse2.Fuseholder
4.Replacethefuseinthefuseholder(Figure25).
Note:Yourmowercomeswithasparefuseinthe
batterycompartment.
5.Installthebatterycompartmentwiththescrewthat
youremovedinstep3.
6.Installthecoveringoverthebatterycompartment.
7.Lowerthereardeector.
ReplacingtheBlade
ServiceInterval:Yearly
Important:
Y ou will need a torque wr ench to install
the blade pr oper l y
.Ifyoudonothaveatorque
wrenchorareuncomfortableperformingthis
procedure,contactanAuthorizedServiceDealer.
Examinethebladewheneveryourunoutofgasoline.If
thebladeisdamagedorcracked,replaceitimmediately.
Ifthebladeedgeisdullornicked,haveitsharpenedand
balanced,orreplaceit.
WARNING
Thebladeissharp;contactingthebladecanresult
inseriouspersonalinjury.
Weargloveswhenservicingtheblade.
1.RefertoPreparingforMaintenance.
2.Tipthemowerontoitssidewiththeairlterup.
3.Useablockofwoodtoholdthebladesteady
(
Figure26).
Figure26
4.Removetheblade,savingallmountinghardware
(Figure26).
5.Installthenewbladeandallmountinghardware
(
Figure27).
Figure27
Important:Positionthecurvedendsofthe
bladetopointtowardthemowerhousing.
6.Useatorquewrenchtotightenthebladeboltto
60ft-lb(82N-m).
Important:Abolttorquedto60ft-lb(82N-m)
isverytight.Whileholdingthebladewitha
blockofwood,putyourweightbehindthe
