Setup
Important:Removeanddiscardtheprotective
plasticsheetthatcoverstheengine.
1
InstallingtheHandle
NoPartsRequired
Procedure
WARNING
Foldingorunfoldingthehandleimproperlycan
damagethecables,causinganunsafeoperating
condition.
•Donotdamagethecableswhenfoldingor
unfoldingthehandle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Removethehandleknobsfromthemowerhousing
(
Figure3).
Important:Routethecablestotheoutsideof
thehandleknobsasyouinstallthehandle.
Figure3
2.Movethehandletotheoperatingposition.
3.Installandtightenthehandleknobsthatyou
removedinstep
1(Figure3).
2
FillingtheEnginewithOil
NoPartsRequired
Procedure
Important:Yourmowerdoesnotcomewithoil
intheengine,butitdoescomewithabottleofoil.
Beforestartingtheengine,lltheenginewithoil.
Max.ll:20oz.(0.59l),type:SAE30detergentoil
withanAPIserviceclassicationofSF,SG,SH,SJ,SL,
orhigher.
Note:Whenthecrankcaseisempty,pourabout3/4of
thecrankcasecapacityofoilinthecrankcase,thendo
thefollowing:
1.Movethemowertoalevelsurface.
2.Removethedipstickbyrotatingthecap
counterclockwiseandpullingitout(Figure4).
Figure4
1.Dipstick
3.Wipethedipstickcleanwithacleancloth.
4.Insertthedipstickfullyintotheoillltube,then
removethedipstick.
5.Readtheoillevelonthedipstick.
Note:IftheoillevelisbelowtheAddmarkonthe
dipstick,slowlypourasmallamountofoilintothe
oillltubeandrepeatsteps
3through5untiltheoil
levelisattheFullmarkonthedipstick(
Figure4).
5
