g208181
Figure4
1.Handlelockengaged
position
2.Handlelockdisengaged
positions
2.Setthehandlelock(Figure5)untilthepinclicks
inplacetolockthehandleintotheoperating
position.
g206253
Figure5
1.Handlelock2.Pin
Note:T oadjustthehandleheight,refertoAdjusting
theHandleHeight(page10).
2
InstallingtheRecoil-starter
RopeintheRopeGuide
NoPartsRequired
Procedure
Important:Tostarttheenginesafelyandeasily
wheneveryouusethemachine,installthe
recoil-starterropeintheropeguide.
Holdtheblade-controlbartotheupperhandleand
pulltherecoil-starterropethroughtheropeguideon
thehandle(Figure6).
g003251
Figure6
1.Recoil-starterrope2.Ropeguide
3
FillingtheEnginewithOil
NoPartsRequired
Procedure
Important:Yourmachinedoesnotcomewithoil
intheengine,butitdoescomewithabottleofoil.
Beforestartingtheengine,lltheenginewithoil.
Engineoilcapacity:0.5L(16.9oz)
Oilviscosity:SAE30orSAE10W-30detergentoil
APIserviceclassication:SJorhigher
1.Movethemachinetoalevelsurface.
2.Removethedipstickbyrotatingthecap
counterclockwiseandpullingitout(Figure7).
