FIG8. MONO AMPLIFIER WIRING (MULTI-WOOFER LOAD)
4 OH M
4 OH M
*EQUIVALENT PARALLEL WOOFER LOADS CANNOT BE LESS THAN THE MINIMUM STABLE LOAD RATED IN THIS
MANUAL. THE TWO NEGATIVE AND TWO POSITIVE SPEAKER TERMINALS ARE WIRED INTERNALLY INSIDE EACH
AMPLIFIER.
ONLY ONE NEGATIVE AND ONE POSITIVE ARE NEEDED WHEN WIRING TO THE AMPLIFIER.
THESE ARE MONO-BLOCK AMPLIFIERS AND NOT MULTI-CHANNEL AMPLIFIERS.
THE MINIMUM LOAD FOR ALL “MONO RAGE” (MONOBLOCK) AMPLIFIERS ARE 1-OHM, EXCEPT "R2"
(2-OHM MINIMUM).
