Toro RX2 - RX2 Amplifier Wiring Configurations; RX2 1-Channel Mode Wiring; RX2 2-Channel Mode Wiring

FUSE
DESIGNED & ENGINEERED IN U.S.A.
1
2
4
BRIDGED
X2
PWR/ PRO
DESIGNED & ENGINEERED IN U.S.A.
10V 0.2
HPF
FIG9. (1-CHANNEL MODE)RX2 AMPLIFIER WIRING
FUSE
DESIGNED & ENGINEERED IN U.S.A.
1
2
4
BRIDGED
X2
PWR/ PRO
DESIGNED & ENGINEERED IN U.S.A.
10V 0.2
HPF
FIG10. (2-CHANNEL MODE)RX2 AMPLIFIER WIRING
MINI M U M I M P E D A N C E FOR
BRI D G E D I N S TA LLATI O N I S 4 - O H M
MINI M U M I M P E D A N C E FOR
STER E O I N S TA L LATIO N I S 2 - O H M
