SL500 Lawn Tractor

Model No. 13AP62RP544

Register your product at www.Toro.com

769-03029 (1/25/07)

l

a

u

na

M

s

’

r

o

t

a

r

e

p

O

Form No. 3357-954 Rev. A

Table of Contents

Questions and Answers:

S
Samuel CarpenterAug 12, 2025
How to start a Toro SL500 when the engine fails to start?
- T
  Tracy PughAug 13, 2025
  If your Toro Lawn Mower engine won't start, try these steps: * Ensure the PTO knob or lever is disengaged (OFF). * Engage the parking brake. * Connect the wire(s) to the spark plug(s). * Move the Throttle/Choke Control to the CHOKE position. * Pull out the CHOKE control (if equipped) or place the throttle control in CHOKE. * Fill the tank with clean, fresh gas (less than 30 days old). * Clean the fuel line or replace the fuel filter (if equipped). * Clean, adjust the gap, or replace the spark plug. * Crank the engine with the throttle in the FAST position.
A
Ann GibsonAug 16, 2025
Why my Toro Lawn Mower will not mulch grass?
- D
  daniel34Aug 16, 2025
  Your Toro Lawn Mower might not be mulching grass effectively because: * The engine speed is too low. Place the throttle control in the FAST position. * The grass is wet. Avoid mowing when the grass is wet; wait until it's dry. * The grass is excessively high. Mow once at a high cutting height, then mow again at the desired height, or make a narrower cutting swath. * The blade is dull. Sharpen or replace the blade.
N
Nicole LynchAug 20, 2025
How to fix poor idling on my Toro SL500 Lawn Mower?
- S
  Stacie McgeeAug 20, 2025
  To address poor idling in your Toro Lawn Mower, you can try the following: * Replace the spark plug(s) if they are fouled, faulty, or have a gap that is too wide. * Set the spark plug(s) gap. * Replace the air cleaner cartridge/element or clean the pre-cleaner, if equipped.
J
jacobolsonAug 25, 2025
What causes an uneven cut with my Toro Lawn Mower?
- C
  Christopher GonzalezAug 25, 2025
  An uneven cut with your Toro Lawn Mower may be due to: * A deck that is not balanced properly. Perform a side-to-side deck adjustment. * A dull blade. Sharpen or replace the blade. * Uneven tire pressure. Check the tire pressure in all four tires.
S
Shane GreenAug 27, 2025
What to do if my Toro Lawn Mower engine runs erratically?
- T
  Tina JacobsAug 27, 2025
  If your Toro Lawn Mower engine is running erratically, consider the following: * Push the CHOKE control in (if equipped) or move the throttle control out of the CHOKE position. * Connect and tighten the spark plug wire(s). * Clean the fuel line and fill the tank with clean, fresh gasoline (less than 30 days old). * Replace the fuel filter, if equipped. * Clear the vent or replace the cap if damaged. * Drain the fuel tank and refill it with clean, fresh gasoline (less than 30 days old). * Replace the air cleaner cartridge/element or clean the pre-cleaner, if equipped.
K
Kristina RodgersAug 31, 2025
Why is my Toro Lawn Mower engine overheating?
- A
  Andrew SmithAug 31, 2025
  Your Toro Lawn Mower engine might be overheating due to: * Low engine oil level. Fill the crankcase with the proper capacity and weight of oil. * Restricted airflow. Clean grass clippings and debris from around the engine’s cooling fins and blower housing.
D
Dana Larson MDSep 4, 2025
What causes excessive vibration in my Toro Lawn Mower?
- J
  John TuckerSep 4, 2025
  Excessive vibration in your Toro Lawn Mower could be caused by: * A loose or unbalanced cutting blade. Tighten the blade and spindle. * A damaged or bent cutting blade. Balance the blade. * Consider replacing the blade.
P
Philip ClaytonSep 7, 2025
What to do if Toro Lawn Mower engine hesitates at high RPM?
- A
  Alicia RamirezSep 7, 2025
  If your Toro Lawn Mower engine hesitates at high RPM, it could be because the spark plug(s) gap is too close. Remove the spark plug(s) and reset the gap.

Toro SL500 Specifications

General

Brand	Toro
Model	SL500
Category	Lawn Mower
Language	English

Summary

Important Safe Operation Practices

General Operation

Read and follow all instructions before operating the machine.

Slope Operation

Guidelines for safe operation on inclines to prevent tip-overs.

Children Safety

Safety precautions to prevent accidents involving children.

Safety and Instructional Labels

Slope Gauge

Tractor Set-Up

Attaching The Steering Wheel

Instructions for installing the steering wheel onto the tractor.

Attaching the Battery Cables

Steps for connecting the tractor's battery cables correctly.

Tire Pressure

Recommended tire pressure for safe operation and proper mowing.

Attaching The Seat

Steps for installing and adjusting the tractor seat.

Shipping Brace Removal

Instructions for removing the shipping brace before operation.

Setting the Gauge Wheels

Adjusting deck gauge wheels for proper cutting height.

Gas and Oil Fill-up

Procedures for safely filling the fuel tank and checking oil.

Know Your Lawn Tractor

Tractor Controls Overview

Identification and function of all tractor controls and indicators.

Operating Your Lawn Tractor

Safety Interlock System

Explanation of safety features preventing operation under unsafe conditions.

Reverse Caution Mode

How to enable mowing in reverse, with safety warnings.

Starting the Engine

Step-by-step guide for starting the tractor's engine safely.

Driving The Tractor

Instructions for forward and reverse movement and basic operation.

Stopping the Engine

Procedures for safely shutting down the tractor's engine.

Driving On Slopes

Safe operating procedures and restrictions when mowing on slopes.

Setting The Cruise Control

How to engage and disengage the cruise control feature.

Engaging the Parking Brake

Steps to set and release the tractor's parking brake.

Engaging the PTO (Blades)

Procedure for engaging the cutting deck or other attachments.

Using the Deck Lift Lever

How to adjust the cutting deck height using the lift lever.

Making Adjustments

Seat Adjustment

How to adjust the position of the operator's seat.

Leveling the Deck

Instructions for adjusting the cutting deck for an even cut.

Steering Adjustment

How to adjust steering linkage for proper alignment.

Side to Side (Deck Adjustment)

Adjusting the cutting deck for side-to-side leveling.

Maintaining Your Lawn Tractor

Engine Maintenance

Procedures for engine oil changes, air filter service, and general upkeep.

Fuel Filter

How to inspect and replace the fuel filter.

Cleaning the Engine and Deck

Methods for cleaning the tractor's engine and mowing deck.

Deck Wash System

Instructions for using the deck wash system for cleaning.

Chassis Lubrication

Lubrication points and schedule for the tractor's chassis and components.

Service

Tires

Information on recommended tire pressure and maintenance.

Fuse

Location and replacement instructions for the tractor's fuse.

Cutting Blades

Procedures for sharpening, replacing, and balancing cutting blades.

Battery

Care and handling instructions for the tractor's battery.

Jump Starting

Safe procedures for jump-starting a dead tractor battery.

Charging

Instructions for charging the tractor's battery.

Cutting Deck Removal

Steps for safely removing the mowing deck from the tractor.

Changing the Deck Belt

Procedure for replacing the tractor's deck belt.

Off-Season Storage

Maintenance Chart

Troubleshooting

Specifications
