Controls
Becomefamiliarwithallthecontrolsbeforeyoustart
theengineandoperatethemachine.
ControlPanel
g296034
Figure6
ControlPanel
1.Throttle/chokecontrol
3.Blade-controlswitch
(powertakeoff)
2.Keyswitch
KeySwitch
Thekeyswitch,usedtostartandshutofftheengine,
has3positions:OFF,RUN,andSTART(Figure6).
RefertoStartingtheEngine(page18).
Throttle/ChokeControl
Thethrottleandchokecontrolsarecombinedinto1
controllever.Thethrottlecontrolstheenginespeed
andhasacontinuous-variablesettingfromSLOWto
FAST(Figure6).
Blade-ControlSwitch(Power
Takeoff)
Theblade-controlswitch,representedbya
power-takeoff(PTO)symbol,engagesand
disengagespowertothemowerblades(Figure6).
Motion-ControlLevers
Usethemotion-controlleverstodrivethemachine
forward,reverse,andturneitherdirection(Figure5).
ParkPosition
Movethemotion-controlleversoutwardfromthe
centertothePARKpositionwhenexitingthemachine
(Figure18).Alwayspositionthemotion-controllevers
intothePARKpositionwhenyoustopthemachineor
leaveitunattended.
SmartSpeed™ControlSystem
Lever
TheSmartSpeed™Control-Systemlever,located
belowtheoperatingposition,givesyouachoiceto
drivethemachineat3speedranges—trim,tow,and
mow(Figure21).
Fuel-PresenceWindow
Youcanusethefuelwindow,locatedontheleftside
ofthemachine,toverifythepresenceoffuelinthe
tank(Figure7).
g292100
Figure7
1.Fuel-presencewindow
10

Toro TimeCutter 4200 Specifications

General

Transmission	Hydrostatic
Cutting Width	42 in (107 cm)
Cutting Height	4.5 inches
Fuel Capacity	3 gal (11.4 L)
Warranty	3 years limited
