LevelingfromSidetoSide
1.Movetotheleftsideofthemachine.
2.Settheanti-scalprollerstothetopholesor
removethemcompletelyforthisprocedure;refer
toAdjustingtheAnti-ScalpRollers(page26).
3.Settheheight-of-cutlevertothe76mm(3inch)
position;refertoAdjustingtheHeightofCut
(page26).
4.Place2blocks,eachhavingathicknessof6.6
cm(2-5/8inches),undereachsideofthefront
edgeofthedeckbutnotundertheanti-scalp
rollerbrackets(Figure68orFigure69).
5.Place2blocks,eachhavingathicknessof7.3
cm(2-7/8inches),undertherearedgeofthe
cuttingdeckskirt,1oneachsideofthecutting
deck(Figure68orFigure69).
g298027
Figure68
MowerDeckswith2Blades
1.Woodblock—6.6cm
(2-5/8inches)thick
2.Woodblock—7.3cm
(2-7/8inches)thick
g298028
Figure69
MowerDeckswith3Blades
1.Woodblock—6.6cm
(2-5/8inches)thick
2.Woodblock—7.3cm
(2-7/8inches)thick
6.Removethehairpincotterandwasherfromthe
lowerlift-armpin(Figure70).
g294197
Figure70
1.Height-of-cutplate
3.Washer
2.Hairpincotter
7.Rotatetheheight-of-cutplatetoadifferenthole
sothatitsupportstheweightofthemowerdeck
afteryouinstalltheplate(Figure71).
