InstallingtheBlades
1.Installtherstbladesothatitishorizontal,along
withallmountinghardwareasshowninFigure
41.
Note:Tightentheboltwithyourngers.
Important:Positionthecurvedendsofthe
bladestopointtowardthemachinehousing.
Besuretonesttheraisedareasoneach
bladedriverwiththerecessesintheheadof
itscorrespondingspindle,andthepinson
theothersideofeachbladedriverwiththe
holesinitscorrespondingblade.
2.Steadyeachbladewithaboardandturnthe
bladeboltclockwisewithatorquewrenchas
showninFigure42;torquethebladeboltto82
N∙m(60ft-lb).
g232801
Figure42
3.Rotatetheinstalledblade1/4turnuntilitis
vertical,andinstalltheotherbladeinthesame
mannerastherst(refertostep1).
Note:Thebladesshouldbeperpendicular,
forminganinverted“T”asshowninFigure43.
g016536
Figure43
1.Blade(2)
4.Tightenthesecondblade;refertostep2.
5.Rotatethebladesbyhandafull360°turnto
ensurethattheydonottouch.
Note:Ifthebladestoucheachother,theyare
notmountedcorrectly.Repeatsteps1through
3,untilthebladesnolongertoucheachother.
WARNING
Incorrectlyinstallingthebladescoulddamage
themachineorcauseaninjurytoyouor
bystanders.
Usecarewheninstallingtheblades.
