ProductOverview
g227688
Figure6
1.Height-of-cutdeck-lift
pedal
7.Shockassembly
(machineswithMyRide
only)
2.Height-of-cutpositions8.Seatbelt
3.Transportlock9.Fuelcap
4.Controls
10.Parking-brakelever
5.Motion-controllevers11.Mowerdeck
6.Rollbar
12.Casterwheel
Controls
Becomefamiliarwithallthecontrolsbeforeyoustart
theengineandoperatethemachine(Figure6and
Figure7).
ControlPanel
g037119
Figure7
1.Powerport5.Blade-controlswitch
(powertakeoff)
2.Chokecontrol
6.Keyswitch
3.Throttlecontrol
7.Switchpositionforoptional
lightkit
4.Hourmeter
KeySwitch
Thekeyswitch,usedtostartandshutofftheengine,
has3positions:OFF,RUN,andSTART.Referto
StartingtheEngine(page28).
ChokeControl
Usethechokecontroltostartacoldengine.
ThrottleControl
Thethrottlecontrolstheenginespeed,andithasa
continuous-variablesettingfromtheSLOWtoFAST
position(Figure7).
Blade-ControlSwitch(Power
Takeoff)
Theblade-controlswitch,representedbya
power-takeoff(PTO)symbol,engagesand
disengagespowertothemowerblades(Figure7).
HourMeter
Thehourmeterrecordsthenumberofhoursthe
enginehasoperated.Itoperateswhentheengine
isrunning.Usethesetimesforschedulingregular
maintenance(Figure8).
Safety-InterlockIndicators
Therearesymbolsonthehourmeterthatindicate
withablacktrianglethattheinterlockcomponentis
positionedcorrectly(Figure8).
15
