1
ConnectingtheBattery
NoPartsRequired
Procedure
1.Locatethebatteryandnegativebatterycable.
2.Removetheplasticcapfromthenegativebatterypost.
3.Removethefastenersonthenegativebatterycable,
andusethemtosecurethenegativebatterycableto
thenegativebatterypost(
Figure1).
G018395
2
1
4
3
6
5
Figure1
1.Negativebatterycable4.Negativebatterypostcap
2.Wingnut
5.Carriagebolt
3.Washer6.Negativebatterypost
2
InstallingtheRearHitch
Partsneededforthisprocedure:
1Rearhitch
2
Bolt(5/16x2-1/2inches)
2
Locknut(5/16inch)
Procedure
InstallthebrackettotheframeasshowninFigure2and
Figure3.
g015397
1
2
Figure2
Beforeassembly
1.Bolts2.Locknuts
Figure3
Afterassembly
2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Toro TITAN series and is the answer not in the manual?

Toro TITAN series Specifications

General IconGeneral
TransmissionHydrostatic
Deck MaterialFabricated Steel
Cutting Width60 inches
Engine Displacement747cc
Warranty3-Year / 300-Hour (Limited Residential); 30-Day Commercial
