Toro TITAN series User Manual

3
SettinguptheMotion-control
Levers
NoPartsRequired
Procedure
1.Locatethemotion-controlleversattached,butfolded
downonthemachine.
2.Removetheupperbolt(3/8x1inch)andwasher;
loosenthelowerbolt(3/8x1inch).
3.Raisethemotioncontrolleverstotheuprightposition.
4.Aligntheholesinthemotion-controlleverwiththe
holesinthecontrol-armshaft,andinstallthebolt
andwasherremovedpreviously.Repeatthisforboth
controlslevers.
Note:Handtightenallfasteners.
5.Movethemotion-controlleverstotheparkposition,
raisetheseat,andmovethecontrolleversbacktothe
centerposition(neutral).
6.Verifythatthemotion-controlleversareproperly
aligned.
Note:Adjustasnecessary.Tightenallfasteners.
4
SettinguptheRollover
ProtectionSystem(ROPS)Bar
NoPartsRequired
Procedure
1.Removethebolts(1/2x3inches),washers,andnuts
fromthemiddleholeontheROPSplate(Figure4).
Figure4
Leftsideshown;repeatontherightside
1.Washer3.Middlehole
2.Bolt(1/2x3inches)
4.Nut
2.RotatetheROPStotheuprightposition.
3.Installthebolts(1/2x3inches),washers,andnuts
removedpreviouslyintothemiddlehole(Figure4).
4.Removethebolts(1/2x3inches),washers,andnuts
fromthefourthholeintheROPSplate(Figure5).
3

Toro TITAN series Specifications

General

Transmission	Hydrostatic
Deck Material	Fabricated Steel
Cutting Width	60 inches
Engine Displacement	747cc
Warranty	3-Year / 300-Hour (Limited Residential); 30-Day Commercial
