Toro TITAN ZX 5400 - Driving Forward; Driving Backward

Figure19
1.Motion-control
lever—NEUTRAL-LOCK
position
4.Backward
2.Center,unlockedposition5.Frontofthemachine
3.Forward
DrivingForward
Note:Theenginekillsifthetraction-controlleversare
movedwiththeparkingbrakeengaged.
1.Releasetheparkingbrake.
2.Movetheleverstothecenter,unlockedposition.
3.Tomoveforward,slowlypushthemotion-control
leversforward(Figure20).
G008952
Figure20
DrivingBackward
Note:Alwaysusecautionwhenbackingupandturning.
1.Movetheleverstothecenter,unlockedposition.
2.Togobackward,slowlypullthemotion-controllevers
rearward(Figure21).
G008953
Figure21
22
