Toro TurfMaster 22235 - Product Overview; Controls

ProductOverview
g290632
Figure6
1.Sparkplug(underbrush
guard)
11.Drivebar
2.Side-dischargedeector12.Self-propeladjustment
3.Oillter13.Grassbag
4.Oilll/dipstick
14.Recoil-starthandle
5.Fuel-tankcap15.Rearcutting-heightlever
6.Reardeector16.Fuel-shutoffvalve
7.Blade-control-locklever17.Throttlelever
8.Blade-controlbar
18.Airlter
9.Parkingbrake19.Beltcover
10.Handle20.Frontcutting-heightlever
g019644
Figure7
1.Grassbag3.Side-dischargechute
2.Rear-dischargeplug
4.Side-dischargedeector
Controls
g340478
Figure8
Throttle(Throttlelevernotshownforthesakeofclarity)
1.Choke3.Slow
2.Fast
4.Off
