MaintainingthePrimaryDrive
Clutch
Afterevery400operatinghoursoryearly,cleanand
lubricatetheclutchasfollows:
1.Raiseandlatchthecargobox.
2.Stoptheengine,removethekey,andsettheparking
brake.
3.Removethe3boltssecuringthecovertotheclutch
andremovethecover(Figure46).
Figure46
1.Cover
2.Bolts
4.Thoroughlycleantheinsideofthecoverandthe
innerworkingsoftheclutchusingcompressedair.
Thedustintheclutchwillbecomeairborneand
coulddamageyoureyesoryoucouldinhaleit
causingbreathingdifculties.
Wearsafetygogglesandadustmaskorother
eyeandrespiratoryprotectionwhenperforming
thisprocedure.
5.Lubricatethemovingpartsintheareascircledin
Figure47usingToroDryLubricantSpray,available
throughyourAuthorizedToroDealerorDistributor.
Figure47
6.Installtheclutchcoverandsecureitwiththe3bolts
removedpreviously.
ChangingtheTransaxleFluid
Changethetransaxleuidevery800operatinghoursor
yearly,whicheveroccursrst.
1.Positionthevehicleonalevelsurface,settheparking
brake,turntheignitionoff,andremovethekey.
2.Removethedrainplugfromtherightsideofthe
reservoir(Figure48)andlettheuidowintoa
drainpan.Installandtightentheplugwhentheuid
stopsdraining.
Note:Disposeoftheusedoilatacertiedrecycling
center.
Figure48
1.Drainplug2.Levelindicatorhole
3.Fillthereservoir(Figure49)withapproximately
1-1/2qt.(1.4liters)ofSAE10W30motoroil
oruntiltheoillevelisatthebottomofthelevel
indicatorhole(Figure48).
Figure49
1.Oilll
4.Starttheengineandoperateittollthesystem.
Rechecktheoillevelandreplenishit,ifrequired.
36
