g025317
Figure10
1.Rearcasterfork
3.Placejackstandsatthe
arrows
2.Boltholdingrearframe
6.Removeanddiscardtherear-framesupportand
itshardwarewhichislocatedbehindthedrive
tires.
7.Installtherearcasterwheeltotherearcaster
forkwithabolt(1/2x13inches)andlocknut(1/2
inch)AsshowninFigure11.
8.Torquetheboltto90.8to112.5N∙m(67to83
ft-lb).
g025175
Figure11
1.Bolt(1/2x13inches)3.Locknut(1/2inch)
2.Rearcasterwheel
9.Carefullyremovethejackstandsandlowerthe
machine.
10.Lowerthefrontofthehopper.
11.Tilttheseatup.
12.Placethehoisthooksoneachsideoftheseat
asshowninFigure12.
g026290
Figure12
1.Liftpointsoneachsideoftheseat
Important:Ensurethemowerdeckisinthe
uprightpositionbeforeraisingthefrontof
themachine.
13.Raiseupthefrontofthemachine,justenough
toremoveanddiscardthedecksupportfrom
underthereardeckrollers.
14.Lowerthemachinetotheground.
15.Liftthefrontofthehopperup.
16.Usingthehoist,liftthemachineatthelocations
showninFigure9andFigure12.
17.Removethecratefromunderthemachine.
18.Lowerthemachinetotheground.
19.Whilesupportingthemowerdeck,removeand
discardthe2sidestruts,mountingbrackets,
andtheirhardwareonbothsidesoftheseat
(Figure13).
20.Removeanddiscardthestrutlocatedbetween
thefrontdeck-supportpins(Figure13).
