14.Checkthatthemachinedoesnotcreepinneutralwith
theparkbrakesdisengaged.
AdjustingtheMotion-Control
Damper
Thetopdampermountingboltcanbeadjustedtoobtaina
moredesiredmotion-controlleverresistance.SeeFigure83
formountingoptions.
Figure83
Right-handcontrolshown
1.Torquethelocknutto23N-m(17ft-lb).Theboltmust
protrudepasttheendofthelocknutaftertorquing.
2.Mostresistance(rmestfeel)
3.Damper
4.Mediumresistance(mediumfeel)
5.Leastresistance(softestfeel)
AdjustingtheMotionControl
Neutral-LockPivot
Theangednutcanbeadjustedtoobtainamoredesired
motion-controlleverresistancewhenmovingittothe
neutral-lockposition.SeeFigure84foradjustmentoptions.
1.Loosenthejamnut.
2.Tightenorloosentheangednuttothedesiredfeel.
Note:Formoreresistance,tightentheangednut.
Note:Forlessresistance,loosentheangednut
3.Tightenthejamnut.
Figure84
1.Flangednut2.Jamnut
55
