WAVEFORMS
NOTE:
The following waveforms were measured at the point of the corresponding
balloon number in the schematic diagram.
16 50V 20µs/div
SOUND/AV
0.5V 1ms/div
17
1V 1ms/div
18
200mV 500µs/div19
20
500mV 20µs/div
H-2
