ELECTRICAL REPLACEMENT PARTS LIST

Location No. TSB P/N Reference No. Description

RESISTORS

! R401 BZ210089 R4X5T6273F R,METAL 27K OHM 1/6W

! R404 AE004065 R615U2151J R,FUSE 150 OHM 1/2W

! R408 BZ210092 R4X5T6103F R,METAL 10K OHM 1/6W

! R409 BZ210089 R4X5T6273F R,METAL 27K OHM 1/6W

! R429 AD301700 R635814R7J R,FUSE 4.7 OHM 1W

! R447 BZ210229 R3X28A151J R.METAL OXIDE 150 OHM 2W

! R500 BZ210080 R0G3K2275K RC 2.7M OHM 1/2W

! R501 AD300782 R5Y2CD5R6J R,CEMENT 5.6 OHM 5W

! R508 AD300783 R3X181221J R,METAL OXIDE 220 OHM 1W

! R509 BZ210135 R002T4221J RC 220 OHM 1/4W

R510 AE003327 R00202335J RC 3.3M OHM 1/2W

! R514 BZ210190 R63581R22J R,FUSE 0.22 OHM 1W

! R515 BZ210081 R002T2124J RC 120K OHM 1/2W

! R517 BZ210039 R3X181010J R,METAL OXIDE 1 OHM 1W

! R518 AD300036 R4X5T6562F R,METAL 5.6K OHM 1/6W

! R519 BZ210124 R002T4122J RC 1.2K OHM 1/4W

! R525 BZ210097 R3X18A1R5J R,METAL OXIDE 1.5 OHM 2W

! R538 BZ210206 R002T2155J RC 1.5M OHM 1/2W

! R542 BZ210058 R3X181R68J R,METAL OXIDE 0.68 OHM 1W

! R629 AE000081 R3X28B220J R.METAL 22 OHM 3W

! R803 BZ210099 R3X181153J R,METAL OXIDE 15K OHM 1W

! R805 BZ210099 R3X181153J R,METAL OXIDE 15K OHM 1W

! R807 BZ210099 R3X181153J R,METAL OXIDE 15K OHM 1W

CAPACITORS

! C403 BZ110149 E02LT4471M CE 470 UF 35V

! C414 AD301434 E02LU4101M CE 100 UF 35V

! C418 BZ110041 E02LT3471M CE 470 UF 25V

C420 BZ110203 C0PLRR7W2K CC 820 PF 2KV RR

! C434 BZ110195 E02LU8220M CE 22 UF 100V

C437 BZ210173 P4J7F3474J CMPP 0.47 UF 250V PMS

! C443 BZ110258 P4N8FJ862H CMPP 0.0086UF 1.25KV

! C446 BZ110205 E02LU5220M CE 22 UF 50V

! C448 BZ110204 E0ELFD220M CE 22 UF 250V

! C503 BZ110061 C0JTB0513K CC 0.001 UF 500V B

! C505 BZ110025 P2122B224M CMP 0.22 UF 275V ECQUL

! C506 AD301026 CD39E0M13M CC 0.001 UF 250V

! C508 AE002878 CD39E0MQ3M CC 0.0047UF 250V

C514 BZ110203 C0PLRR7W2K CC 820 PF 2KV RR

! C515 BZ110135 E02L02222M CE 2200 UF 16V

C517 BZ110203 C0PLRR7W2K CC 820 PF 2KV RR

! C519 AD300925 E02LT2102M CE 1000 UF 16V

C521 BZ110092 E5EZFB101M CE 100 UF 160V

! C526 BZ110089 E02LFC221M CE 220 UF 200V

C615 AE003280 E52H05010M CE 1 UF 50V

C819 BZ110247 C0JBB0713K CC 0.001 UF 2KV B

DIODES

D001 BZ410037 D97U03301B DIODE,ZENER MTZJ33B T-77

D106 BZ410054 0021721150 LED SLR-342VCT32

D403 BZ410043 D2WT011E10 DIODE,SILICON 11E1-EIC

D404 BZ410066 D97U06R21B DIODE,ZENER MTZJ6.2B T-77

! D405 BZ410063 D2WTAU02A0 DIODE,SILICON AU02A-EIC

D406 BZ410043 D2WT011E10 DIODE,SILICON 11E1-EIC

D408 BZ410043 D2WT011E10 DIODE,SILICON 11E1-EIC

D409 BZ410043 D2WT011E10 DIODE,SILICON 11E1-EIC

! D410 BZ410063 D2WTAU02A0 DIODE,SILICON AU02A-EIC

! D411 BZ410063 D2WTAU02A0 DIODE,SILICON AU02A-EIC

! D412 BZ410020 D97U05R11B DIODE,ZENER MTZJ5.1B T-77

! D501 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC

! D502 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC

! D503 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC

! D504 BZ410085 D2WXN40050 DIODE,SILICON 1N4005-EIC

! D505 BZ410010 D28T21DQN9 DIODE,SCHOTTKY 21DQ09N-TA2B1

D506 AD300671 D97U01801B DIODE,ZENER MTZJ18B T-77

D508 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

! D509 AD300671 D97U01801B DIODE,ZENER MTZJ18B T-77

! D510 BZ410080 D2WXRU2AM0 DIODE,SILICON RU2AM-EIC

D511 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

! D512 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D513 BZ410010 D28T21DQN9 DIODE,SCHOTTKY 21DQ09N-TA2B1

D514 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D515 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

J2-1
