83
Speaker No Sound (Test signal:
0.5Vrms @1KHz sine waveform)
Audio problem
No Audio issue
Yes
Is the TV volume
set to “Mute”?
Yes
Increase the volume level by
pressing the VOL + button on the
remote control or
- on the TV.
Please make sure the signal cable is
connected and has output. Remove the
headphone.
Note: Speaker will be muted when
headphone is connected.
Check IC19 power
pin6,7,12,13=12Vdc
Yes
Check IC19
audio output
Yes
Yes
Check IC19
output signal
Yes
Check net “MUTE” and “HP” circuit
Check equipment output
No
Check U1
No
IC19 fails
No
To Next Page
