A6
1600XP/XPi Series Installation and Operation Manual – 60616-012
STANDARD MODELS: 14 – 22 KVA (CONT’D)
Capacity 14 kVA (11.9 kW)
1
18 kVA (15.3 kW)
1
22 kVA (18.7 kW)
1, 5
Power Connections Standard – Hard wire
Emergency Power Off Standard – Terminal contacts only
Remote Contacts Standard (INV, BYP, BATT, LB, AC, FLT)
RS232 ASCII Interface Toshiba UPS Communication Protocol 2.0
RemotEye 4
(Standard with XPi)
(Optional with XP)
Remote communications package (HTTP/HTTPS, SNMP, Modbus TCP/RTU,
BACnet IP/MSTP) via RJ-45 or RS-485
Mechanical Design
Enclosure Enclosure of unit made from sheet metal meeting NEMA1 and UL
Size (HxWxD) (max)
39.0 x 17.5 x 36.1 in.
(991 x 445 x 917 mm)
Paint System Powder coating
Fan Panel
Panel mounted on back of UPS to allow for
easy replacement of fans
Battery System
Battery Replacement
Slide out battery packs accessible from front of UPS,
factory or authorized service center serviceable only
Battery Packs Designed for battery acid leakage containment with (6) batteries per pack
Battery Pack Size (HxWxD) max.
5.0 x 7.3 x 19.0 in.
(127 x 185 x 462 mm)
Battery Pack Quantity 8
Battery Manufacturer YUASA
Battery Type REW45-12FR
Toshiba Part Number for Battery
Pack
51896-FS 60995-FS
1. Input/output gures rated for 240 volts unless otherwise stated. Output ratings given for 0.85PF are only valid when
the input voltage is greater than 204 volts; otherwise, ratings given for 0.70PF are applicable.
2. Derate to 18.7 kVA (15.9 kW) for 50 Hz operation.
