ELECTRICAL ADJUSTMENTS
D-3
2-13: Confirmation of Fixed Value (Step No.)
Please check if the fixed values of the each adjustment
items are set correctly referring below. (RF/AV)
Fig. 2-2
White 100%
Red 110%
Fig. 2-3
"A"
"A"
NO.
04
14
15
16
18
20
21
23
24
28
29
FUNCTION
H VCO
BRIGHT MAX
BRIGHT MIN
CONT CENT
CONT MIN
COLOR MAX
COLOR MIN
SHARPNESS
FM LEVEL
TEST MONO
TEST STERIO
STEP NO.
04
170
60
40
20
70
00
43
00
00
00
