H-1
WAVEFORMS
NOTE:
The following waveforms were measured at the point of the corresponding
balloon number in the schematic diagram.
3
200mV 20µs/div
0.5V 5ms/div
4
2
20V 20µs/div
5
1V 20µs/div
6
1V 20µs/div
200mV 20µs/div
8
1V 20µs/div7
DEFLECTION/CRT
14
0.5V 5ms/div
15
20V 20µs/div
16
2V 20µs/div
50V 20µs/div
20
10V 5ms/div
19
200V 20µs/div
17
10V 5ms/div18
21
50V 20µs/div
MICON/CHROMA/TUNER
