ELECTRICAL REPLACEMENT PARTS LIST

Location No. TSB P/N Reference No. Description

DIODES

! D507 BZ410043 D2WT011E10 DIODE,SILICON 11E1-EIC

D508 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

! D509 AD300671 D97U01801B DIODE,ZENER MTZJ18B T-77

! D510 AD301980 D2CF2016L0 DIODE,SILICON FE201-6L49

D511 BZ410020 D97U05R11B DIODE,ZENER MTZJ5.1B T-77

! D512 BZ410010 D28T21DQN9 DIODE,SCHOTTKY 21DQ09N-TA2B1

D514 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D516 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D517 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

! D518 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D519 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D520 BZ410058 D97U08R21B DIODE,ZENER MTZJ8.2B T-77

! D521 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D523 AD300731 D2WXN49370 DIODE,SILICON 1N4937

D528 BZ410021 D97U05R61B DIODE,ZENER MTZJ5.6B T-77

D530 AD300731 D2WXN49370 DIODE,SILICON 1N4937

D602 BZ410023 D97U09R11B DIODE,ZENER MTZJ9.1B T-77

D603 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D604 BZ410058 D97U08R21B DIODE,ZENER MTZJ8.2B T-77

D605 AD300070 D97U01201B DIODE,ZENER MTZJ12B T-77

D606 BZ410043 D2WT011E10 DIODE,SILICON 11E1-EIC

D607 AD300070 D97U01201B DIODE,ZENER MTZJ12B T-77

D608 AD300070 D97U01201B DIODE,ZENER MTZJ12B T-77

D609 AD300070 D97U01201B DIODE,ZENER MTZJ12B T-77

D610 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D702 BZ410022 D97U06R81B DIODE,ZENER MTZJ6.8B T-77

D704 BZ410022 D97U06R81B DIODE,ZENER MTZJ6.8B T-77

D707 BZ410022 D97U06R81B DIODE,ZENER MTZJ6.8B T-77

D708 BZ410022 D97U06R81B DIODE,ZENER MTZJ6.8B T-77

D804 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D805 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

D806 BZ410006 D1VT001330 DIODE,SILICON 1SS133T-77

ICS

IC101 AE007340 I56F07116B IC OEC7116B

IC199 AE007341 A3M9149015 INIT DATA BR24L04F-WE2

! IC401 AE002783 I03TD804N0 IC LA78040N-E

! IC501 BZ410088 0002E00610 PHOTO COUPLER LTV-817M-VB

IC901 AE007342 I03FF27000 IC LA72700V-TLM-E

IC902 BZ611139 I0QF02534V IC NJM2534V(TE2)

IC903 BZ611139 I0QF02534V IC NJM2534V(TE2)

! IC1001 AE007343 I0FSP7822A IC AN17822A

TRANSISTORS

Q105 BZ510090 TPAAB05001 COMPOUND TRANSISTOR KRA102SRTK

! Q401 BZ510040 TDUU024990 TRANSISTOR,SILICON 2SD2499(LB0EC1)

! Q402 BZ510089 TC5T01627Y TRANSISTOR,SILICON 2SC1627_Y(TPE2)

! Q501 BZ510098 T220033260 FET 2SK3326(2)

! Q502 BZ510070 TCAT032034 TRANSISTOR,SILICON KTC3203_Y-AT

Q504 BZ510069 TCATC31980 TRANSISTOR,SILICON KTC3198-AT(Y,GR)

! Q507 AE005873 T8RA030520 TRANSISTOR,SILICON 2SC3052-T1

! Q512 BZ510004 TA3T016240 TRANSISTOR,SILICON 2SA1624-AA

Q601 BZ510070 TCAT032034 TRANSISTOR,SILICON KTC3203_Y-AT

Q602 BZ510105 TCAT03209Y TRANSISTOR,SILICON KTC3209_Y-AT

Q603 BZ510070 TCAT032034 TRANSISTOR,SILICON KTC3203_Y-AT

Q604 AE005873 T8RA030520 TRANSISTOR,SILICON 2SC3052-T1

Q606 BZ510070 TCAT032034 TRANSISTOR,SILICON KTC3203_Y-AT

Q607 BZ510069 TCATC31980 TRANSISTOR,SILICON KTC3198-AT(Y,GR)

! Q609 BZ510105 TCAT03209Y TRANSISTOR,SILICON KTC3209_Y-AT

! Q804 BZ510009 TC3F042170 TRANSISTOR,SILICON 2SC4217(D,E)-RAC

! Q805 BZ510009 TC3F042170 TRANSISTOR,SILICON 2SC4217(D,E)-RAC

! Q806 BZ510009 TC3F042170 TRANSISTOR,SILICON 2SC4217(D,E)-RAC

Q1001 AE005873 T8RA030520 TRANSISTOR,SILICON 2SC3052-T1

Q1003 AE005873 T8RA030520 TRANSISTOR,SILICON 2SC3052-T1

COILS &TRANSFORMERS

! L401 BZ310063 022100027A COIL,LINEARITY ELH5L4113

! L501 BZ310144 029T000097 COIL,LINE FILTER 1R5A123F28Y

! L503 BZ310033 028R200026 COIL,DEGAUSS 8R200026

L901 BZ310041 02167F101J COIL 100 UH

L903 BZ310041 02167F101J COIL 100 UH

T401 BZ310157 045009003J TRANS,HORIZONTAL DRIVE ETH09K14BZ

! T501 AE006212 048135091S TRANSFORMER,SWITCHING 8135091S
