ELECTRICAL REPLACEMENT PARTS LIST
Location No. TSB P/N Reference No. Description
JACKS
J701 AE002759 060J431020 RCA JACK MSP-213V2-432_NI_LF
J710 AE004756 060J401104 RCA JACK MTJ-032-03A-30FE
J711 AE004758 060J401106 RCA JACK MTJ-032-03A-32FE
J712 AE004757 060J401105 RCA JACK MTJ-032-03A-31FE
! J801 AD301356 066F130020 SOCKET,CATHODE RAY,TUBE ISHS53S
! J1001 AE003431 060J131016 HEADPHONE JACK MSJ-2000_AG
SWITCHES
SW101 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW102 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW103 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW104 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
SW105 BZ612010 0504101T34 SWITCH,TACT EVQ21505R
VARIABLE RESISTORS
VR401 BZ210218 V1K63H3BTE VOLUME,SEMI FIXED NVG6TLTAB222
VR402 BZ210237 V1K63Q4BTE VOLUME,SEMI FIXED NVG6TLTAB473
VR502 BZ210101 V1163H4BTC VOLUME,SEMI FIXED EVNCYAA03BE4
P.C.BOARD ASSEMBLIES
PCB010 AE007344 A3M9149010 PCB ASS'Y CME026A
PCB110 AE007345 A3M9149110 PCB ASS'Y CCE021A
MISCELLANEOUS
! B501 BZ310121 024HT03553 CORE,BEADS W5RH3.5X5X1.0
! B503 BZ310121 024HT03553 CORE,BEADS W5RH3.5X5X1.0
! B504 BZ310121 024HT03553 CORE,BEADS W5RH3.5X5X1.0
BT001 AE005640 141R004016 BATTERY,MANGAN GR03X-SP2
BT002 AE005640 141R004016 BATTERY,MANGAN GR03X-SP2
! CD501 AE007346 1209415911 CORD,AC BUSH 9415911
CD801 AE005637 06CH823004 CORD,CONNECTOR CH823004
CD802 AE004077 WCL6848038 FLAT CABLE AWM2468 A WG26 5C GRAY 480MM
CD803 BZ614493 WBL6032038 FLAT CABLE AWM2468 A WG26 4C BLACK 320MM
CP401 BZ614303 069S450089 CONNECTOR PCB SIDE A1561WV2-A5P
CP402 BZ614016 069W01001A CONNECTOR PCB SIDE 003P-2100
! CP502 AE006748 069S420099 CONNECTOR PCB SIDE A1561WV2-2PK
CP503 BZ614016 069W01001A CONNECTOR PCB SIDE 003P-2100
CP601 AE001188 069S270639 CONNECTOR PCB SIDE A2001WR2-7P
CP801 BZ614269 069S320010 CONNECTOR PCB SIDE A2361WV2-2P
CD1001 AD301449 06CH14411A CORD,CONNECTOR CH14411A
CP1001 AD301045 069S140419 CONNECTOR PCB SIDE A2502WV2-4P
CP802A BZ614276 067U005049 WIRE HOLDER B2013H02-5P
CP802B BZ614276 067U005049 WIRE HOLDER B2013H02-5P
CP803A BZ614334 067U004029 WIRE HOLDER B2013H02-4P
CP803B BZ614334 067U004029 WIRE HOLDER B2013H02-4P
EL001 BZ614043 124116281A EYE LET XRY16X28BD
EL002 BZ614044 124120301A EYE LET XRY20X30BD
! F501 BZ614422 081PC6R305 FUSE 51MS063L
! FB401 AE004292 043221025F TRANSFORMER,FLYBACK FQI21B002R_M
FH501 AE002634 06710T0009 HOLDER,FUSE EYF-52BCY
FH502 AE002634 06710T0009 HOLDER,FUSE EYF-52BCY
OS101 AD301048 0773071001 REMOTE RECEIVER RPM7138-WH5
! RY501 AE006070 0560X20118 RELAY G5PA-1-SA(WEC)
! SP1001 AE007347 070N457008 SPEAKER YDP512-22
! SP1002 AE007347 070N457008 SPEAKER YDP512-22
! TH501 AD302000 D8EE0B1400 DEGAUSS ELEMENT B59203-S1060-B14
TM101 AD301451 076N0EH030 TRANSMITTER RC-EH030
! TU001 AE006069 0163300018 RF UNIT 115-V-KA35ARB
! V801 AE001906 098Y210452 CRT W/DY A51LZM10X16N45
X601 AD301653 100DT3R531 CRYSTAL HC-49/U
RESISTOR
RC................... CARBON RESISTOR
CAPACITORS
CC................... CERAMIC CAPACITOR
CE................... ALUMI ELECTROLYTIC CAPACITOR
CP................... POLYESTER CAPACITOR
CPP.................. POLYPROPYLENE CAPACITOR
CPL.................. PLASTIC CAPACITOR
CMP................... METAL POLYESTER CAPACITOR
CMPL................ METAL PLASTIC CAPACITOR
CMPP................ METAL POLYPROPYLENE CAPACITOR
J2-3
