WAVEFORMS
NOTE: The following waveforms were measured at the point of the corresponding
balloon number in the schematic diagram.
H-2
0.5V 1ms/div
32
0.5V 1ms/div
33
SOUND
25
0.5V 1ms/div
26
200mV 1ms/div
200mV 1ms/div
27
28 200mV 1ms/div
31
200mV 1ms/div
