ELECTRICAL REPLACEMENT PARTS LIST

Location No. TSB P/N Reference No. Description

RESISTORS

! R402 72796031 R3K181102J R,METAL OXIDE 1K OHM 1W

! R408 72795515 R4X5T6472F R,METAL 4.7K OHM 1/6W

! R424 72794609 R4X5T6333F R,METAL 33K OHM 1/6W

! R426 72795519 R65581010J R,FUSE 1 OHM 1W

! R429 72798015 R655811R8J R,FUSE 1.8 OHM 1W

! R439 72797842 R3X181181J R,METAL OXIDE 180 OHM 1W

! R500 72794631 R0G3K2275K RC 2.7M OHM 1/2W

! R501 72794615 R5X2AE1R2J R,CEMENT 1.2 OHM 7W

! R502 72794633 R63881R22J R,FUSE 0.22 OHM 1W

! R514 72794616 R002T4682J RC 6.8K OHM 1/4W

! R515 72794642 R002T4103J RC 10K OHM 1/4W

! R517 72797911 R3X28AR82J R,METAL OXIDE 0.82 OHM 2W

! R519 72795995 R3X181R27J R,METAL OXIDE 0.27 OHM 1W

! R520 72795500 R002T2155J RC 1.5M OHM 1/2W

! R521 72797899 R3X28A101J R,METAL OXIDE 100 OHM 2W

! R527 72797911 R3X28AR82J R,METAL OXIDE 0.82 OHM 2W

! R534 72794666 R803R9101J RC 100 OHM 1/16W

! R543 72797851 R3X181331J R,METAL OXIDE 330 OHM 1W

! R629 72795502 R3X18A470J R,METAL OXIDE 47 OHM 2W

! R635 72795502 R3X18A470J R,METAL OXIDE 47 OHM 2W

! R803 72794659 R3X18A123J R,METAL OXIDE 12K OHM 2W

! R805 72794659 R3X18A123J R,METAL OXIDE 12K OHM 2W

! R807 72794659 R3X18A123J R,METAL OXIDE 12K OHM 2W

CAPACITORS

C120 72797159 CQG0CH4N2J CC 390 PF 50V CH

C121 72797469 E52H05100M CE 10 UF 50V

C402 72794399 C0PLRR713K CC 0.001 UF 2KV R

! C414 72794380 E02LU4101M CE 100 UF 35V

! C418 72794360 E02LF3102M CE 1000 UF 25V

! C420 72795069 C0JTB05H3K CC 0.0022UF 500V B

! C430 72781641 P235W1683J CMP 0.068 UF 100V MKT

! C434 72794396 E02LU8220M CE 22 UF 100V

! C446 72794379 E02LU5220M CE 22 UF 50V

! C448 72797431 E0ELTD100M CE 10 UF 250V

C449 72795565 P4J7F3334J 0.33 UF 250V PMS

! C453 72797716 P4N8FJ912H CMPP 0.0091UF 1.25KV

! C501 72797424 E0ELF2222M CE 2200 UF 16V

! C502 72795578 C0JBB0713K CC 0.001 UF 2KV B

! C503 72795578 C0JBB0713K CC 0.001 UF 2KV B

! C505 72794401 P2122B334M CMP 0.33 UF 275V ECQUL

! C506 72795567 P2122B104M CMP 0.1 UF 275V ECQUL

! C507 72795568 E51CGC331M CE 330 UF 200V

! C513 72797413 E02LU54R7M CE 4.7 UF 50V

! C514 72797083 C03L0R7E3K CC 0.0015UF 2KV R

! C517 72795073 C0PLRR7G3K CC 0.0018 UF 2KV R

! C521 72795571 E62NFB221M CE 220 UF 160V

! C527 72797477 E5EZF2222M CE 2200 UF 16V

! C528 72795579 CD39E0MQ3M CC 0.0047UF 250V

! C654 72797156 CQG0B0415K CC 0.1 UF 50V B

C802 72795578 C0JBB0713K CC 0.001 UF 2KV B

C1024 72781381 E02LF2332M CE 3300 UF 16V

DIODES

D001 72794465 D97U03301B DIODE,ZENER MTZJ33B T-77

D101 72794489 D97U05R61B DIODE,ZENER MTZJ5.6B T-77

D102 72794489 D97U05R61B DIODE,ZENER MTZJ5.6B T-77

D107 72795529 0021721150 LED SLR-342VCT32

! D404 72794469 D97U05R11B DIODE,ZENER MTZJ5.1B T-77

D405 72794490 D97U06R21B DIODE,ZENER MTZJ6.2B T-77

! D406 72794488 D2WT011E10 DIODE,SILICON 11E1-EIC

! D407 72794472 D2WTAU02A0 DIODE,SILICON AU02A-EIC

! D410 72794472 D2WTAU02A0 DIODE,SILICON AU02A-EIC

! D411 72794472 D2WTAU02A0 DIODE,SILICON AU02A-EIC

D412 72794488 D2WT011E10 DIODE,SILICON 11E1-EIC

D417 72794480 D28T21DQN9 DIODE,SCHOTTKY 21DQ09N-TA2B1

D418 72794465 D97U03301B DIODE,ZENER MTZJ33B T-77

D419 72794465 D97U03301B DIODE,ZENER MTZJ33B T-77

! D501 72794473 D2WTRM11C0 DIODE,SILICON RM11C-EIC

! D502 72794473 D2WTRM11C0 DIODE,SILICON RM11C-EIC

! D503 72794473 D2WTRM11C0 DIODE,SILICON RM11C-EIC

! D504 72794473 D2WTRM11C0 DIODE,SILICON RM11C-EIC

! D505 72794474 D28F0PRA60 DIODE,RECTIFIER 30PRA60-FC

! D506 72796387 D97U01301B DIODE,ZENER MTZJ13B T-77

! D507 72794488 D2WT011E10 DIODE,SILICON 11E1-EIC

D508 72794491 D1VT001330 DIODE,SILICON 1SS133T-77

! D509 72795541 D97U01801B DIODE,ZENER MTZJ18B T-77
